TEREX MDS MT24L

The MDS MT24L Low Level Feeder Conveyor allows operators to directly discharge from wheel loaders and excavators at a significantly lower feed in height compared to standard hopper feeders. The unique design of the hopper allows for rear feeding which can be an advantage when operating in restricted areas.

The pinless deployment allows for rapid set up times, meaning you get your return on investment in record time. The machine is operated by radio remote, meaning you can ensure the safety of your team on site.

Common applications for this machine include barge loading and trimming using parallel tracking, railroad carriage loading, windrowing, bay loading and confined site operating.

PRODUCTION CAPACITY: Up to 600 tonnes per hour.
ENGINE: CAT 4.4
WEIGHT: 29,550kg
HOPPER: AR400 Hopper
BELT WIDTH: 1300mm discharge belt for streamlined material flow.
FEEDER LENGTH: 4.1m
DISCHARGE HEIGHT: 8m
MAX. DISCHARGE HEIGHT: 10.7m
TRANSPORT DIMENSIONS: 20m long x 3.6m high x 3.2m wide
WORKING DIMENSIONS: 20m long x 5m high x 7m wide

FEATURES
Automatic greasing cartridges at head drum.
Hydraulic folding head section.
Kick out/kick in pressure sensor.
Hydraulically driven orbital slew ring.
Undercarraige with heavy duty tracks.
Twin hydraullic drive feed conveyor.
Tubular feed support frame as standard.
Radio remote to track, slew, start/stop feeder, raise/lower discharge conveyor and tip grip.
Adjustable height
Pinless deployment for a rapid setup
